FP series
FP series is specially designed for entertainment engineering, inheriting the sound and high stability of ON power amplifier, novel appearance, compact structure, superb craftsmanship and reliable quality.
Product Features:
Excellent signal conversion characteristics, with very small harmonic distortion, intermodulation distortion, transient intermodulation distortion
Complete protection system, it has peak detection circuit, efficient and perfect protection of speakers
The sound is pure and natural, the middle and high frequencies are transparent, the low frequencies are full and strong, and the outstanding music expression makes you never forget
Full-featured high-speed protection circuit, using high-quality toroidal transformers and world-class high-efficiency Class H circuits
The raw materials are carefully selected, tested repeatedly, and carefully built to make the sound of this series of power amplifiers natural and clear, dynamic and powerful, and the sound is transparent, and the high, medium and low frequencies are distinct.
Very suitable for high-end KTV, entertainment clubs, bars, etc.
Product parameters:
|
model |
FPT350 |
FPT450 |
FPT650 |
FPT800 |
FPT900 |
FPT1300 |
FPT1600 |
|
stereo output 4 ohm |
2X500W |
2X600W |
2X1000W |
2X1200W |
2X1400W |
2X2000W |
2X2300W |
|
stereo output 8 ohm |
2x350W |
2X450W |
2X650W |
2X800W |
2X900W |
2X1300W |
2X1600W |
|
bridged output 8 ohm |
|
|
1800W |
2400W |
2600W |
4000W |
4600W |
|
Input sensitivity |
0db(0.775V rms) 1.0V/26dB |
||||||
|
Frequency response range |
20-20000Hz(±0.3dB) |
||||||
|
Slew rate |
≥30V/us |
||||||
|
Damping Factor |
≥400:1 |
≥600:1 |
|||||
|
Cross talk Cross talk |
＞70dB@1KHz |
||||||
|
S/N ratio |
＞100dB |
||||||
|
Total harmonic distortion (THD) |
＜0.1%,1K Hz |
||||||
|
Intermodulation distortion (IMD) |
＜ 0.2% ( 8Ω ,1KHZ@1W) |
||||||
|
Protections |
Short-circuit protection, overload protection, overheat protection, DC protection, anti-interference, switch protection, mute, pressure limit |
||||||
|
Product size (WxHxD) |
483x88x410mm |
483x88x480mm |
|||||
|
Net weight |
14.5KG |
15KG |
18KG |
20KG |
21KG |
24.5KG |
27KG |
