CNX12

Product Type:

12" coaxial speaker

Product Features:

CNX12 is a high-quality coaxial loudspeaker with balanced timbre performance, giving singers a comfortable listening effect. The coaxial diffusion method brings a better listening effect for singers performing on stage mobile performances, regardless of the song Whether facing the speaker or deviating from the speaker, the accompaniment effect can be heard clearly. CNX12 also has a very useful design, which can be set at different angles according to different placement positions. The two angle controllers for storage and deployment allow CNX12 to be used freely.

Product parameters:

Rated power: 430W / 860W / 1720W (continuous/program/peak)

Rated impedance: 8Ω

Frequency range (-10db): 40Hz-20KHz

Frequency response (±3db): 48Hz-18KHz

Maximum sound pressure level: 124dB SPL continuous / 130dB SPL peak

System sensitivity: 98dB(1w@1m)

Bass driver: 1×12""

Tweeter driver: 1×1.75""

Radiation angle: 90°×90°

Crossover frequency: 1.9kHz

Box appearance: birch plywood / black water-based paint

Steel mesh: powder layer / black / 1.5mm perforated steel / black acoustic cloth inside

Input connector: Speakon®NL-2 1/4" combination×2

Box size: 500×341×496mm (W×H×D)

Net weight: 20Kg"
